660V 55Kwh LTO Electric Transit Van Battery System
Cells: LTO 14Ah Pouch cell
Case Number: 4 HV-C, 1 String
Rated Voltage: 662.4V
Rated Capacity: 84Ah
Rated Energy: 55.6Kwh
BMS: ISO 26262 certification
LTO Electric Transit Van Battery System
Description
Specifications
| Item | Specification | Remark |
| Nominal capacity | 84Ah | @25℃，±5% |
| Nominal voltage | 662.4V | |
| Charging limiting voltage | 751.8V | |
| Discharging limiting voltage | 483.5V | |
| Nominal energy | 55.6kWh | |
| Weight | 416Kg | |
| Constant charging current | 400A | cooling with air conditioner |
| Constant discharging current | 400A | |
| Peak discharging current | 500A | 10s，@50%SOC |
| Ingress protection | IP67 | |
| Working temp range | Charging: -10℃~55℃
Discharging：-20℃~55℃ |
